Description
Features
- IP65 water and dust protection with shock-resistant design for vehicle use
- 1-inch tempered IPS capacitive touchscreen (1280 px × 800 px) with high brightness
- Intel N5100 quad-core platform with Windows 10 or 11 support for industrial apps
- 8 GB RAM and 128 GB eMMC with microSD expansion up to 512 GB
- Direct car charging and wide-voltage support plus optional emergency battery
- Rich I/O: RJ45, USB-A 3.0, USB-C (where configured), RS232, RS485 and SIM slot
- Built-in GNSS (Neo-7) supporting GPS, Beidou and GLONASS; optional 4G and NFC
- Programmable function keys, waterproof speaker and rugged mounting options
Technical Specifications
| Processor | Intel Jasper Lake N5100 quad-core (up to 2.8 GHz) |
| Operating System | Windows 10 or Windows 11 (configurable) |
| RAM | 8 GB DDR (standard) |
| Storage | 128 GB eMMC (standard) |
| Expandable Storage | MicroSD, TF card up to 512 GB |
| Display | 10.1-inch tempered glass IPS capacitive touchscreen |
| Display Resolution | 1280 px × 800 px |
| Brightness | 700 cd per m² |
| GPU, Graphics | Intel HD Graphics (Gen 11 LP) |
| Speaker, Microphone | Built-in Waterproof Speaker (1.5 W); internal mic |
| Keys & Indicators | Power; Volume +/-; 4 programmable function keys; RGB indicator |
| Network & Cellular | Wi-Fi 802.11 a b g n ac (2.4 GHz & 5.8 GHz); optional 4G module |
| Bluetooth | Bluetooth 5.0 (BLE) |
| GNSS | Neo-7 module GPS, Beidou, GLONASS |
| I/O Interfaces | USB Type-A 3.0 ×1, DC-IN, RJ45 (10,100,1000 Mbps), RS232 ×1, RS485 ×1 |
| SIM & Card slots | Nano-SIM ×1; TF card slot ×1 |
| Optional Modules | 4G modem, NFC (NXP300), car charger, Wi-Fi, GPS antennas |
| Power & Battery | Optional 7.4 V, 1000 mAh Li-Poly emergency battery; standard cable, DC powering |
| Charging | Direct car charging supported; external adapter, wide-voltage options |
| Environmental Protection | IP65 (dust-tight and water resistant against sprays) |
| Humidity | Up to 95% RH non-condensing |
| Drop Resistance | Designed for vehicle vibration and multiple drops to meet vehicle use profiles |
| ESD Immunity | ± 15 kV (air), ± 8 kV (contact) |
| Operating Temperature | −4 °F to 140 °F (−20 °C to 60 °C) |
| Storage Temperature | −22 °F to 158 °F (−30 °C to 70 °C) |
| Dimensions (Product) | 10.41 in × 7.25 in × 0.91 in (264.5 mm × 184.1 mm × 23.0 mm) |
| Weight (Product Only) | 1.838 lb (834g) |
